Arzel Zoning
HeatPumPro® offers the latest in zoning control technology with its built-in staging and software-based programming. The technology is the easiest and most cost-effective way of getting the maximum efficiency out of heat pump systems. The custom defaults are stored in memory so it is possible to commission this system with the touch of a button.
While the HeatPumPro was originally designed specifically for heat pump applications, the flexibility of the software has made it possible to use it with other heating and cooling systems, such as a heat pump with electric backup, conventional, and dual fuel. Even single-stage equipment can be zoned, because the HeatPumPro only needs to be reprogrammed when the system is upgraded, not replaced.
The HeatPumPro is perfect for both new construction and retrofit applications, offering the most versatile, cost-effective zoning system in the industry.
| Item ID | Item Description |
|---|---|
| PAN-HPP02 | HeatPumPro® 2-zone panel |
| PAN-HPP03 | HeatPumPro® 3-zone panel |
| PAN-HPP04 | HeatPumPro® 4-zone panel |
The HeatPumPro works with any standard 24-volt system including split geothermal, heat pump, and conventional furnace and air conditioner. This makes the HeatPumPro® perfect for both new construction and retrofit applications.
The HeatPumPro is run by software so it allows you to program the system according to a homeowner’s comfort needs. This makes it extremely versatile and gives the homeowner the opportunity to save money while increasing their comfort.
By controlling fan speed independently, little or no bypass is required with the HeatPumPro panel, which improves the efficiency of the equipment and saves the homeowner on utility bills.
The HeatPumPro is equipped with an LCD screen allowing you access to real-time reporting of the system’s activities. This will save time and money on installation.
The HeatPumPro can be equipped with an optional solenoid to control the humidifier bypass damper. There is also a built-in fossil fuel kit and advanced dual-fuel technology included in the panel’s software, eliminating the need for additional controls. These options make the panel the most cost-effective, efficient option to zone any home or office.
No! Arzel recommends the HeatPumPro for most applications. HeatPumPro can be used on any forced air single-stage, furnace, A/C, dual fuel, fossil fuel, or geothermal system. It is our best control for variable speed equipment.
No, you can use heat/cool thermostats on all zones. If you want access to emergency heat using the system’s heat pump, you will need a heat pump thermostat in zone one. Otherwise, emergency heat would be controlled by the HeatPumPro when using a heat/cool thermostat.
Yes. The system will not operate properly without the outdoor air temperature (OAT) sensor installed. However, it does not need to go outside unless the HeatPumPro is controlling a heat pump.
The HeatPumPro will need to open all the system dampers in the event of an A2L refrigerant leak. You’ll connect the HeatPumPro to your equipment’s refrigerant detection system (RDS) or A2L mitigation board using a relay. See our A2L guide to learn how.
